NAY2Y

Download PDF

Add to inquiry

Download PDF

To inquiry

PVC/PE aluminium energy cable

Power Cables and Overhead Lines 0.6/1 kV

Power distribution cables in power stations, industrial installations and switch gears, as well as in local mains. For fixed installation under ground, in interior premises, cable ducts, in the open air and in water – as permitted by the local building regulations – under severe mechanical stressing during installation and operation.

Design

This product consists of:

  • 1
    Aluminium conductor, round solid (RE), sector-shaped solid (SE), round stranded (RM), resp. sector-shaped stranded (SM)
  • 2
    Core insulation (PVC)
  • 3
    Inner covering (EPDM)
  • 4
    Sheath (HDPE black, UV-resistant)

Technical Data

Standard: DIN VDE 0276-603 (HD 603)
Certificate: VDE Germany
Test Voltage: core/core 4 kV / 50 Hz
Rated Voltage: 0,6/1 kV
Bending radius (min.):
  • 12 x Ø of cable (multicore)
  • 15 x Ø of cable (singlecore)
Core identification: HD 308 S2
Temperature range:
  • Laying temperature: min. -5°C
  • Operating temperature: -50°C up to 70°C
  • Conductor temperature: max. 70°C
  • Short circuit temperature: max. 160°C
Cable image - NAY2Y
+
-
Cable image - NAY2Y
+
-
Cable image - NAY2Y
+
-

Contact us

Are you interested in this product?

Vojtěch Cuřín

Product supervisor

+420 731 226 023
[email protected]

Options

Add to inquiry
Number of cores x nominal cross-section (mm²)
Max. conductor resistance (Ω/km)
Current rating in the earth (A)
Current rating in the air (A)
Outer diameter appr. (mm)
Total weight appr. (kg/km)
4 x 25 RE
1.2
102
82
26.3
884
4 x 35 RE
0.868
123
100
28.6
1099
1 x 50 RM
0.641
230
166
18.1
389
4 x 50 SE
0.641
144
119
29.9
1210
1 x 70 RM
0.443
283
210
19.6
476
4 x 70 SE
0.443
179
152
33.3
1545
4 x 70 SM
0.443
179
152
34.7
1619
1 x 95 RM
0.32
340
259
21.8
603
4 x 95 SE
0.32
215
186
38.0
2052
1 x 120 RM
0.253
389
302
23.1
697
4 x 120 SE
0.253
245
216
41.1
2434
1 x 150 RM
0.206
436
345
25.0
824
4 x 150 SE
0.206
275
246
45.0
2923
4 x 150 SM
0.206
275
246
48.5
3074
1 x 185 RM
0.164
496
401
27.1
986
4 x 185 SE
0.164
313
285
49.6
3608
4 x 185 SM
0.164
313
285
53.9
3782
1 x 240 RM
0.125
578
479
29.9
1221
4 x 240 SE
0.125
364
338
59.8
4743
4 x 240 SM
0.125
364
338
55.2
4795
1 x 300 RM
0.1
656
555
32.8
1474
1 x 400 RM
0.078
756
653
37.2
1870
1 x 500 RM
0.061
873
772
40.5
2286
1 x 630 RM
0.047
1011
915
46.2
2853

Technical changes reserved.

All figures are therefore without guarantee.
