PVC insulated wire
Instalation and Harmonised Cables and Wires
PVC insulated wires for fixed and protected installations, for internal wiring of equipment and lightings, for signalling and control circuits.
Design
This product consists of:
- 1Bare copper conductors, fine wires class 5 according to DIN EN 60228 / VDE 0295 / IEC 60228
- 2Core insulation of special compound based on polyvinyl chloride (PVC)
Technical Data
Standard: EN 50525-2-31
Test Voltage: 2000 V
Rated Voltage: 300/500 V (Uo/U)
Bending radius (min.):
- Fixed installation: 3 x Ø of cable
- Flexible use: 5 x Ø of cable
Fire properties:
- EN 60332-1-2: self-extinguishing and flame retardant
- CPR classification: Eca
Core identification: According to EN 50525-1 - black, white, blue, brown, red, orange, violet, pink, green/yellow, yellow, green, grey
Temperature range:
- Laying temperature: min. 5°C
- Fixed installation: -30°C up to 70°C
- Flexible use: -5°C up to 70°C
